1X2 Fiber Optic Splitter requirement of NOS Portugal

Below is detail requirements of fiber optic splitter from NOS operator in Portugal

Fiber type: ITU G.657.A1

Mode type: SM 9/125

Fiber core manufacturer: not requiried

Input fiber diameter: 250um

Output fibers diameter: 250um

Cladding diameter: not required

Input buffer diameter: 900um

Input buffer length: 6mm

Input/Output connectors: Without connectors

Input fiber length: 1.5m

Output fibers length: 3m

Output fiber color coding: Colored

Operating Wavelength Range: 1260~1360 and 1460~1650

Insertion Loss max: 0.8 + 3.4 log2 N (outputs)

Return Loss min: not requiried

Directivity min: not requiried

Uniformity: not requiried

PDL max: not requiried

Module dimension (LxWxH): 40x4x4mm

Operating Temperature: -40 to 85ºC

Module material: Stainless steel

Serial Number: Mandatory

Serial Number label type: not requiried

All testing procedures must comply with Telcordia GR-1209 and GR-1221 Requirements, IEC or EN equivalent, third-party certified.
